HPC COATING

HPC® Coating is designed to control heat transfer on surface temperatures up to 900°F (482°C). It is water-borne and extremely lightweight in appearance. HPC® Coating uses a special acrylic resin blend with specific ceramic compounds added to provide a non-conductive block against heat transfer.

HPC® Coating offers a “Green”, non-flammable, non-toxic formula for high heat surface applications over standard steam pipe or oven wall construction. HPC® Coating is easily applied using a texture sprayer, and can be applied over metal, concrete, wood, and other substrates.

If HPC® Coating is to be applied over flat steel surfaces, see manufacturer for instructions.





TYPICAL USES:



  • As an insulation system over hot pipes, tanks, and valves.
  • To block heat migration into cold tanks, lines, and valves.
  • As a system to block conductive and convective heat.
  • Easily applied when a hot system cannot be shut down.





APPLICATION METHOD:



HPC® Coating should only be used for applications less than 700°F (371°C) degree ; if over 700F, apply according to manufacturer's instructions. HPC® Coating can be used for applications over 700°F (371°C) up to 900°F (482°C) but only according to the manufacturer's instructions. HPC® Coating can be applied to metal, concrete, masonry and wood. The application is applied using a texture sprayer. For specific instructions on surface preparation, mixing and application, please refer to the SPI Application Instruction sheet for HPC® Coating.
